Where it fits. Thermoplastic elastomer is a quiet, non-marking tread built for finished floors. It combines the low rolling resistance of a hard wheel with a cushioned ride that absorbs floor seams and thresholds, which reduces both noise and the push force an operator has to apply. This swivel model rotates a full 360 degrees and is normally specified two per cart with two rigid casters at the opposite end, or four per cart where the equipment has to move sideways in tight aisles.
Construction. The body is molded from glass filled nylon and will not rust or corrode. It uses a threaded stem attachment. This model is supplied with a total lock brake. A steel precision sealed bearing carries the load.
Load and duty. The 200 lb rating is per caster. Standard practice is to size a four-caster set assuming three casters carry the load, so this model supports roughly a 600 lb cart with margin for shock loading and uneven floors. Continuous operating range is -4°F to 122°F.
About the line. The Tandem Low Height series delivers the twin wheel layout and full total lock brake of the standard Tandem in a compact form factor, for equipment where mount height is constrained.
Standard Features:
Also available:
- Without a brake — MP29T47075PAFG18
- With threaded stem (T27 – M10 X 25mm) — MP29T27075PAFG13AG
- With threaded stem (T37 – 1/2″ – 13 X 1″) — MP29T37075PAFG13AG
- Without a brake, with threaded stem (T27 – M10 X 25mm) — MP29T27075PAFG18
Custom options:
- Custom tread and body colors
- Conductive wheels
- Stainless steel for washdown service
- Private label or custom branding
Please consult factory for all customizations.
