A 4″ medium/heavy duty TPU wheel with a 2″ crown tread in blue on tan and running on a 1/2″ quad x bearing with a 2-1/2″ hub. It carries 600 lb and operates from -30°F to 140°F, with a Shore A98 tread.
| Product Series | |
|---|---|
| Series Type | Medium/Heavy Duty |
| Wheel Diameter | |
| Wheel Tread Width | |
| Hub Width | |
| Wheel Profile | |
| Wheel Tread Material | TPU |
| Wheel Core Material | Polypropylene |
| Wheel Durometer | |
| Wheel Color | |
| Bearing Type | |
| Wheel Bore Size | 1/2" |
| Bearing Material | |
| Load Capacity | |
| Bearing Size | |
| Operating Temp | |
| Weight | |
| Warranty Duration | |
| Threadguard |
Where it fits. Thermoplastic polyurethane is the general-purpose upgrade tread. It is non-marking, resists oils and most mild chemicals, and carries more load than rubber at the same diameter without the noise of a hard tread. TPU holds its shape under sustained static load, so carts parked loaded overnight are less prone to flat spots.
Construction. The tread is molded to a polypropylene core. Hub width is 2-1/2″. A 1/2″ steel Quad X bearing fits a 1/2″ axle.
Load and duty. The 600 lb rating is per wheel. Standard practice is to size a four-wheel set assuming three wheels carry the load, so this wheel supports roughly an 1,800 lb cart with margin for shock loading and uneven floors. Continuous operating range is -30°F to 140°F.
About the line. PatriotPro wheels carry a domestically produced TPU tread for medium and heavy duty service, combining high load capacity with non-marking floor protection and resistance to oils and mild chemicals. Made in the USA.
