A 5″ shopping cart Superwheel wheel with a 1-1/4″ crown tread in blue on gray and running on a 5/16″ quad x bearing with a 1-9/16″ hub. It carries 250 lb and operates from -30°F to 140°F, with a Shore A65 soft rubber body.
| Product Series | |
|---|---|
| Series Type | Shopping Cart |
| Wheel Diameter | |
| Wheel Tread Width | |
| Hub Width | |
| Wheel Profile | |
| Wheel Tread Material | Soft Rubber |
| Wheel Core Material | Polypropylene |
| Wheel Durometer | |
| Wheel Color | |
| Bearing Type | |
| Wheel Bore Size | 5/16" |
| Bearing Material | |
| Load Capacity | |
| Bearing Size | |
| Operating Temp | |
| Options/Features | |
| Weight | |
| Warranty Duration | |
| Threadguard |
Where it fits. Superwheel is our flat-spot-resistant line, using a cushioned tread that recovers its shape after a cart sits loaded, so wheels parked overnight still roll smoothly the next morning. Soft rubber is specified where quiet operation and floor protection outweigh capacity. The compliant tread absorbs shock and bridges floor seams, thresholds, and debris that would stop a harder wheel. Expect a lower load rating and more rolling effort than a hard tread of the same diameter.
Construction. The tread is molded to a polypropylene core. Hub width is 1-9/16″. Thread guards are fitted to keep string, film, and debris out of the bore. A 5/16″ steel Quad X bearing fits a 5/16″ axle.
Load and duty. The 250 lb rating is per wheel. Standard practice is to size a four-wheel set assuming three wheels carry the load, so this wheel supports roughly a 750 lb cart with margin for shock loading and uneven floors. Continuous operating range is -30°F to 140°F.
About Series 30. Series 30 wheels are built for retail and shopping cart service. P&H has specialized in shopping cart wheels since the 1980s, and the line includes travelator and moving walkway wheels for carts found primarily outside the US market.
