Suitable for various applications including food equipment, institutional, material handling, retail, conveyor systems, automotive, distribution/logistics, food/beverage, food service, garden center, hospitality, institutional, janitorial, loading dock, material handling, medical, medical/laboratory, pharmaceutical/laboratory, retail environment, stocking, and towing operation.
- Material handling
- Distribution
- Back room
- Industrial
- Platform & stock trucks
- Dollies
- Trash, mail & cargo containers
- Freight terminal trucks
- Automotive Equipment
- Toolboxes
- Commercial kitchen equipment
- Janitorial Equipment
Р&H has developed a broad line of casters and wheels to make light work of heavy loads. Our products are designed to handle loads up to 1500 lbs. with ergonomics and maneuverability in mind to make any type of cart manageable in a wide range of environments.
Our Medium/Heavy duty line is constantly expanding to meet the needs of the wide range of industries that have a requirement for these products.
- Caster Finish: Zinc Plated, Non-Heat Treated
- Attachment Method: Imperial Plate
- Attachment Size: P3 4″ x 4 1/2″ Plate
- Wheel Diameter: 8″
- Tread Width: 2″
- Hub Width: 2 1/8″
- Tread Material: TPR
- Wheel Color: Gray on Gray
- Bearing: Roller
- Axle Type/Bore Size: 1/2″
- Threadguard: Yes
- Overall Height: 9 1/2″
- Load Capacity (lbs): 600 lbs
- Durometer: A70
- Operating Temp (°F): -30 to 140
- Brake Type: No Brake
- Function Type: Standard
- Packaging: 0 to 240
- Warranty Duration: One Year Warranty
- Caster Type: Swivel
- Product Series: 40 Series
- Series Type: 40: Medium/Heavy Duty
- Wheel Part Number: WK4082G86
- Plate Hole Center: 3″ x 3.625″
- Swivel Radius: 3.00″
- Wheel Profile: Round Tread
P&H Medium/Heavy duty casters and wheels are available in several finishes, with a wide selection of wheels.
The options for brakes, bearing and other features are as unlimited as your requirements. If you don’t see what you need in our standard inventory of products, talk to us about specialized design!
- Top, side and total lock brakes
- Full size threadguards
- Precision/Dual Precision and Quad X bearings
- Delrin and Roller Bearings
- Sealed raceways
- Plain Bore / No Bearing or Spanner Bushings
- Tread Material: TPR
- Wheel Diameter: 8″
- Load Capacity: 600 lbs
- Bearing Type: Roller
- Attachment Size: P3 4″ x 4 1/2″ Plate
