Front view of Z26M654NTKILD swivel caster highlighting dual precision bearings and total lock brake.
Front view of Z26M654NTKILD swivel caster highlighting dual precision bearings and total lock brake.
Rear view of Z26M654NTKILD swivel caster showing wheel and mounting plate.
Side view of Z26M654NTKILD swivel caster with a 5-inch anti-static TPR wheel.

Z26M654NTKILD

Industrial swivel caster with a 5″ anti-static TPR wheel, zinc-plated finish, and load capacity of 300 lbs, featuring a total lock brake with dual pedals for secure positioning.

  • Caster Type:Swivel
  • Tread Width:1 1/4"
  • Wheel Diameter:5"
  • Wheel Type:TPR
  • Capacity:300 LBS
  • Finish:Zinc Plated Steel with Lacquer Dip
Category: Tags: , , , , , , , , , , , ,
Add to Quote
Compare

Additional information

Caster Type

Wheel Part No

Wheel Material

Attachment Method

Caster Finish

Product Series

Series Types

Industry

, , , ,

Application

, , , , ,

Imperial Plate Size

Overall Height

Plate Hole Centers

Swivel Radius

Weight

Wheel Diameter

Wheel Tread Width

Wheel Color

Axle Size

Bearing Type

Bearing Material

Wheel Profile

Hub Width

Wheel Durometer

Load Capacity

Operating Temp

Bearing Size

Warranty Duration

  • The Z26M654NTKILD caster is perfect for a variety of industrial applications, including:
    • Sensitive electronic environments
    • Medical equipment
    • Industrial machinery
    • Material handling equipment
    • Institutional carts Its anti-static properties, high load capacity, and total lock brake make it ideal for environments requiring reliable and durable mobility solutions that prevent static build-up and provide secure positioning.
  • Wheel Diameter: 5 inches
  • Wheel Material: Anti-static TPR (Thermoplastic Rubber)
  • Finish: Zinc-plated
  • Load Capacity: 300 lbs
  • Durometer: Shore A86 (+/-5)
  • Bearing Type: Dual Precision Bearings
  • Swivel Radius: 3.937 inches
  • Mounting Type: Metric Plate
  • Mounting Bolt Hole Pattern: 2.893″ x 3.150″
  • Bolt Size: 3/8-16 UNC
  • Temperature Range: -30°F to 140°F
  • Application: Industrial, sensitive electronic environments
  • Wheel Color: Gray on Tan
  • Brake: Available with side lock brake
  • Custom mounting plates available on request
  • Stainless steel version available
